Unmanaged 4+2 100Mbit POE Switch
6 Port POE Switch
4 port PoE 100Mbit · 2 100Mbps Uplink Port
6 Port POE Switch
6 Port POE Switch(4 port PoE 100Mbit)
· PoE Port: 4 10/100Mbps RJ45 port,Max 15.4W
· PoE data & power transmission distance:100meters(100Mbps),250meters(10Mbps)
· Uplink Port: 2 100Mbps RJ45,Transmission Distance: 100m
· POE standard: IEEE802.3af
· POE type: 1/2+ 3/6-
· Power adaptor: 52V 1.44A 75W
|
Model Number |
POE6-402-NP75 |
|
Power |
|
|
Power Adapter Voltage |
110-240V AC |
|
Consumption |
75W |
|
Network |
|
|
POE Ethernet Port |
1-4 Port: 10/100Mbps |
|
Ethernet Port |
Uplink Port: 10/100/1000Mbps |
|
Transmission Distance |
1-8 Port:100Mbps:0-100m 10Mbps:0-250m |
|
Transmission Medium |
Cat5/5e/6 standard network cable |
|
Network Standard |
IEEE 802.3/802.3u, IEEE802.3x, IEEE802.1d |
|
Switching Capacity |
1Gbps |
|
Packet Forwarding Rate |
0.74Mbps |
|
MAC Table |
2K |
|
Power Over Ethernet |
|
|
POE Standard |
IEEE802.3af |
|
POE Power Supply Type |
End-Span (1/2[$add],3/6-) |
|
POE Power Consumption |
af = 15.4W (each port) |
|
LED Indicator |
|
|
Power |
1 red light indicates that the power normal work |
|
POE |
4 yellow lights indicate that the POE is power on |
|
Ethernet |
6 green lights indicate that the Ethernet link and act |
|
Environment |
|
|
Working Temperature |
0℃-55℃ |
|
Relative Humidity |
20-95% |
|
Storage Temperature |
-20℃- 70℃ |
|
Mechanical |
|
|
Dimension ( L x W x H ) |
201mm*120mm*41mm |
|
Color |
Black |
|
Weight |
605g |
|
Stability |
|
|
MTBF |
>30000h |
